Metal Bracket (IR-MB02) - 22mm(0.86in), 26mm(1.02in), 27mm(1.06in) Stroke Version Lateral mounting
Metal Bracket (IR-MB02) - 22mm(0.86in), 26mm(1.02in), 27mm(1.06in) Stroke Version Lateral mounting
Metal Bracket (IR-MB02) - 22mm(0.86in), 26mm(1.02in), 27mm(1.06in) Stroke Version Lateral mounting
Metal Bracket (IR-MB02) - 22mm(0.86in), 26mm(1.02in), 27mm(1.06in) Stroke Version Lateral mounting
Metal Bracket (IR-MB02) - 22mm(0.86in), 26mm(1.02in), 27mm(1.06in) Stroke Version Lateral mounting
Metal Bracket (IR-MB02) - 22mm(0.86in), 26mm(1.02in), 27mm(1.06in) Stroke Version Lateral mounting
Metal Bracket (IR-MB02) - 22mm(0.86in), 26mm(1.02in), 27mm(1.06in) Stroke Version Lateral mounting

Metal Bracket (IR-MB02) - 22mm(0.86in), 26mm(1.02in), 27mm(1.06in) Stroke Version Lateral mounting

Regular price $16.00 $0.00

Product description

  • Use IR-MB02 metal bracket to mount the servo onto applications tightly. Referring to published drawings, user is also able to make this bracket at their end if necessary.
  • This is for 22mm(0.86in) & 26mm(1.02in) & 27mm(1.06in) stroke version only (40mm(1.57in) ~ 96mm(3.78in) stroke versions have built-in mounting holes)

Installation

Please be aware of sharp edges of metal bracket (IR-MB02) when you assemble.

Make sure to put spring washer before M2.6 L5 screw is applied. (See Red circle on image#② above.) Otherwise, it may damage the servo motor inside.

MightyZAP can be mounted by IR-MB02 without directivity. See Installation method A and B above.





Apply M3 screws to 4 x M3 mounting holes.(M3 screws are not included.)


Video
